Series X Kegerator Base Unit Keg Fridge

Series X Kegerator Base Unit Keg Fridge

This new kegerator model is a big step up from the older Series 4 model.  This new Series X has several major advancements:

1. It is 10% more power efficient
2. 15% faster cooling and better cooling in hotter climates
3. Thicker walls for improved insulation
4. FITS 4 CORNY KEGS (purchased separately)

This Kit includes:

1 x Series X Base Model Kegerator includes:
   1 x KL07429 MK4 KegLand Regulator with 1 x  8mm duotight x FFL fitting
   1 x KL00192 Black Plastic Wrap Around Drip Tray
   1 x KL00222 Set of 4 Castor Wheels + bolts. (2 x Front Locking, 2 Free Spinning)
   1 x KL00215 CO2 Cylinder Holder (designed to suit 2.6kg gas cylinder)
   1 x KL00208 Chrome Plated Guard Rail with rubber locking feet.
   1 x Wire Shelf (included if you want to convert it back to a can/bottle fridge)
   1 x KL24051 NEW! Carbonation Chart Sticker
Please note: These items cannot be removed from the pack.

If you want a full kegerator package you will need a FONT PACK, TAPS, CONNECTION PACK, GAS CYLINDER and KEGS.

FONT PACK - you will need one of these 4 different font options
a) KL00475 Single Tap Font Kit
b) KL00482 Double Tap Font Kit
c) KL00499 Triple Tap Font Kit
d) KL15745 Quadruple (Four) - 4 Tap Font Kit

TAPS
a) KL15509 NukaTap Stainless Steel
b) KL26482 NukaTap Stainless Steel - Black - Punisher Edition
c) KL15523 NukaTap Stainless Steel Flow Control

CONNECTION PACK - this is the different connection types to fit the various different kegs that exist
a) KL08815 A-type Keg Coupler (If you are using a 50L A-type Keg you will also need a low profile elbow bend)
b) KL08822 D-type Keg Coupler
c) KL20756 duotight 8mm (5/16") x Ball Lock Disconnect (Grey+ Red/Gas) and KL20749 duotight 9.5mm (3/8") x Ball Lock Disconnect - (Black + Yellow Liquid) Ball Lock fittings for 19L cornelius kegs.

GAS CYLINDER

KEGS
Options a and b are good options for home brewing but option c) is the best choice if you want to purchase commercial beer.
a) KL02899 19L Ball Lock Kegs. This is the most popular option for home brewing.
b) KL02882 9.5L Ball Lock kegs.
c) No kegs.  If you want to get commercial beer from a brewery this normally comes in a keg so no need to purchase your own.

Series X Dimensions
- 600mm Wide
- 650mm Deep
- 840mm Height (excluding castor wheels and the height of guard rail, drip tray or font)
- 890mm Height of the fridge part (including castor wheels but excluding the height of guard rail, drip tray or font)

To download the Series X dimensioned drawings click here

HOW MANY KEGS CAN FIT IN THE SERIES X FRIDGE?

19L Ball Lock Kegs - Up to 4
9.5L Ball Lock Kegs - Up to 4
20L and 30L All Stainless Commercial Kegs - up to 3 x 20L kegs or 1 x 20L keg and 1 x 30L keg
50L Keg - 1

Please note most A-type kegs are too tall to fit in the Series X without a "KL00390 - Low Profile Elbow Bend" as well as an EPDM 5/8" Washer on the couplers liquid out side (sold seperately).
